Viper R/C Solutions
Viper R/C Product Alert
Viper VTX10R Product Spec

Viper VTX10

Viper VTX10
On Resistance: 0.00045 *2
Support Li-Po Cell: 2S-3S Lipo/LiFe
Max BEC Voltage/AMP: 7V/5A
Motor limit: 2-pole 540/6.5T @2S
Dimensions: 30x32.5x14.5mm

Viper VTX10R
On Resistance: 0.00025 *2
Support Li-Po Cell: 2S-3S Lipo/LiFe
Max BEC Voltage/AMP: 7V/5A
Motor limit: 2-pole 540/2.5T @ 2S
2-pole 550/4.5 @ 2S
Dimensions: 30x32.5x19.5mm

Viper VTX10 Speed Control
Viper VTX Sensored Speed Control is the most advanced speed control system available. Fully adjustable, ROAR approved, ultra small footprint makes the VTX the clear choice in your hunt for podium finishes. With two versions to choose from the VTX10 and VTX10R you have options for which speed control better suits your needs.

The VTX's all aluminum case disperses heat without the use of a fan. Both speed control's come preloaded with eight profiles which are all customizable. Or add your own profile for a track or track condition. The VTX10 is designed to handle down to a 6.5 turn sensored motor in two wheel drive applications. The VTX10R is capable of running the larger VST XL 550 motors designed for today's popular 4x4 short course racers and 540 motors with no limit on motor turns.

The same size as a credit card, the Progauge is used for tuning the speed control while at the track without the need for a computer. The innovative V-Port on the VTX speed control allows for programmability without removing the speed control wire from the receiver. This means less wear over time and you never have to dig for your receiver to make a small adjustment. Features of the Viper R/C VTX Speed Controls

All these features are complimented with a 365 day limited warranty on all Viper R/C electronics.
Viper VST XL Media
Viper VTX10 ESC Viper VTX10 ESC Viper VTX10 ESC Viper VTX Side
Viper ProGauge Viper VTX Box Viper VTX10 ESC

Viper Downloads

Cautions!

  • You need a Viper PC Link (P/N GVSPCLINK1) to use this software.
  • The software is designed for specific ESC models. Make sure you download the correct software for your ESC.
  • Compatible with only MS Windows.

Firmware
Version
Release
Date
   Description Download
A55 7/20/2012
  • Improved radio calibration process.
  • Improved boost performance.
  • Improved brake performance.
  • V-Link Software for firmware updating and profile management,
    and ESC settings.
  • Good for both on and off road.
  • For VTX10 and VTX10R only.

A64 2/1/2014
  • New profiles specifically designed for on and off road applications.
  • New logic algorithms to improve overall performance (throttle and brake responses) with better efficiency that lower both ESC and motor temperature.
  • Improved and optimized boost performance with more power and brake control.
  • Improved Low Voltage Cut off design for better power management without a hard shutdown to the system.
  • Newly designed motor error detection to prevent ESC damage with alternating F and R flashing error code.
  • Added motor rotation option.
  • Enable boost in practice mode.


Team Viper Setup Sheets

Driver Name Chassis/Class Track Download Remarks
Travis Amezcua Durango DESC410 / 4WD SC Hot Rod Hobbies 2012 Hot Rod Shootout A-Main
Andrew Smonik Team C Evo / 2WD Buggy 17.5 Boost Hot Rod Hobbies 2012 Hot Rod Shootout A-Main
