| On Resistance: | 0.00025 *2 |
| Support Li-Po Cell: | 2S-3S Lipo/LiFe |
| Max Peak Bec Voltage/Amp: | 7V/5A |
| Motor limit: | 540/NoLimit |
| Dimensions: | 30x32.5x19.5mm |
|
|
| On Resistance: | 0.00045 *2 |
| Support Li-Po Cell: | 2S-3S Lipo/LiFe |
| Max Peak Bec Voltage/Amp: | 7V/5A |
| Motor limit: | 540/6.5T |
| Dimensions: | 30x32.5x14.5mm |
|
|
| Case Length: | 2.12in/52.80mm |
| Case Diameter: | 1.42in/36.00mm |
| Shaft Length: | 2.6in/13.8mm |
| Shaft Extension: | 0.58in/14.8mm |
| Weight: | 6.35oz/180g |
| Poles: | 2 Poles |
|
|||
| Model | Turns | KV | Watts |
| VST2.5 | 2.5T | 12600 | 713 |
| VST3.5 | 3.5T | 9500 | 617 |
| VST4.5 | 4.5T | 7400 | 512 |
| VST5.5 | 5.5T | 6300 | 470 |
| VST6.5 | 6.5T | 6100 | 441 |
| VST7.5 | 7.5T | 4400 | 392 |
| VST8.5 | 8.5T | 4000 | 304 |
| VST9.5 | 9.5T | 3600 | 270 |
| VST10.5 | 10.5T | 3100 | 255 |
| VST13.5 | 13.5T | 2400 | 203 |
| VST17.5 | 17.5T | 1900 | 157 |
| VST21.5 | 21.5T | 1500 | 101 |
| VST25.5 | 25.5T | 1400 | 90 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
| Part Name | Part Number |
| VTX10 sensored brushless system with VST6.5 | 6VSVT10010 |
| VTX10 sensored brushless system with VST7.5 | 6VSVT10002 |
| VTX10 sensored brushless system with VST8.5 | 6VSVT10003 |
| VTX10 sensored brushless system with VST9.5 | 6VSVT10004 |
| VTX10 sensored brushless system with VST10.5 | 6VSVT10005 |
| VTX10 sensored brushless system with VST13.5 | 6VSVT10006 |
| VTX10 sensored brushless system with VST17.5 | 6VSVT10007 |
| VTX10 sensored brushless system with VST21.5 | 6VSVT10008 |
| VTX10 sensored brushless system with VST25.5 | 6VSVT10009 |
| VTX10R sensored brushless racing system with VST2.5 | 6VSVT10R02 |
| VTX10R sensored brushless racing system with VST3.5 | 6VSVT10R03 |
| VTX10R sensored brushless racing system with VST4.5 | 6VSVT10R04 |
| VTX10R sensored brushless racing system with VST5.5 | 6VSVT10R05 |
| VTX10R sensored brushless racing system with VST6.5 | 6VSVT10R06 |
| VTX10R sensored brushless racing system with VST7.5 | 6VSVT10R07 |
| VTX10R sensored brushless racing system with VST8.5 | 6VSVT10R08 |
| VTX10R sensored brushless racing system with VST9.5 | 6VSVT10R09 |
| VTX10R sensored brushless racing system with VST10.5 | 6VSVT10R10 |
| VTX10R sensored brushless racing system with VST13.5 | 6VSVT10R11 |
| VTX10R sensored brushless racing system with VST17.5 | 6VSVT10R12 |
| VTX10R sensored brushless racing system with VST21.5 | 6VSVT10R13 |
| VTX10R sensored brushless racing system with VST25.5 | 6VSVT10R14 |
| Part Name | Part Number |
| Brushless sensor harness 70mm | 8VSPLINE01 |
| Brushless sensor harness 100mm | 8VSPLINE02 |
| Brushless sensor harness 150mm | 8VSPLINE03 |
| Brushless sensor harness 200mm | 8VSPLINE04 |
| Brushless sensor harness 280mm | 8VSPLINE05 |
| VST tune up rotor 12.00mm RPM type, ROAR spec | 8VSPVSTR01 |
| VST modified class factory default rotor 12.30mm 2.5T to 6.5T, ROAR spec | 8VSPVSTR02 |
| VST modified class factory default rotor 12.50mm 7.5T to 9.5T, ROAR spec | 8VSPVSTR03 |
| VST spec class factory default rotor 12.50mm 10.5T to 21.5T, ROAR spec | 8VSPVSTR05 |
| VST tune up rotor 12.80mm TORQUE type | 8VSPVSTR04 |
| VST tune up rotor 12.00mm RPM type, ROAR spec | 8VSPVSTR01 |
| VST Front cap and screw kit | 8VSPVST001 |
| VST End cap and screw kit | 8VSPVST002 |
| VST Power wires solder tab unit | 8VSPVST003 |
| VST sensor unit | 8VSPVST004 |
| VST bearing set | 8VSPVST005 |
| 12GA wire, Black/Red/Orange, 3ft each color | 6VSPLINE02 |
| 14GA wire, Black/Red/Orange, 3ft each color | 6VSPLINE03 |
| Part Name | Part Number |
| VTX10/10R/1 series ESC power capacitor unit pre-soldered on circuit board | 6VSPCAP001 |
| VTX10/10R/1 series ESC power capacitor without circuit board (2 pcs) | 6VSPCAP002 |
| 10GA wire, Black/Red/Orange, 3ft each color | 6VSPLINE01 |
| 12GA wire, Black/Red/Orange, 3ft each color | 6VSPLINE02 |
| 14GA wire, Black/Red/Orange, 3ft each color | 6VSPLINE03 |
| ProGauge 5 in 1 multi-function meter | 6VSCARD001 |
| VTX 4X Power Capacitor Module | 6VSPCAP003 |
