Viper RC Helicopter ESC
Viper R/C’s Air Series brushless airplane ESC are ready to perform the best with your RC airplanes. It has wide range of selection from light weight 10A to heavy duty 120A. The Air Series ESC has the most robust structure with all aluminum case to provide maximum thermal performance and durability. It equips strong BEC that supports up to 3A and to support up to 6S Li-Po.

All Air Series ESCs feature:

  • Easy ESC setting process with radio transmitter
  • Programmable Motor Timing for the best efficiency/performance demands
  • Programmable Li-Po Battery Management System that automatically detects Li-Po cell number
  • Programmable Flying Mode (Normal / Brake / Soft Start)
  • Build-in thermal protection that cuts motor power when ESC reaches 230 °F



Air 10
P/N 6VSAR01001
Support Li-Po Cell 2S~3S
BEC Linear
Continuous Current 10A
Burst Current (15 Sec with proper air flow) 12A
Dimension (mm) 41x14x8
Wire Size 20awg
Weight (g) 7g
Download User Manual

Air 25
P/N 6VSAR02501
Support Li-Po Cell 2S~3S
BEC Linear
Continuous Current 20A
Burst Current (15 Sec with proper air flow) 25A
Dimension (mm) 42x27x12
Wire Size 16/18awg
Weight (g) 24g
Download User Manual

Air 40
P/N 6VSAR04001
Support Li-Po Cell 2S~6S
BEC Switching
Continuous Current 40A
Burst Current (15 Sec with proper air flow) 50A
Dimension (mm) 64x30x12
Wire Size 14awg
Weight (g) 47g
Download User Manual









Air 60
P/N 6VSAR06001
Support Li-Po Cell 2S~6S
BEC Switching
Continuous Current 60A
Burst Current (15 Sec with proper air flow) 75A
Dimension (mm) 64x30x14
Wire Size 14awg
Weight (g) 59g
Download User Manual


Air 80
P/N 6VSAR08001
Support Li-Po Cell 2S~6S
BEC Switching
Continuous Current 80A
Burst Current (15 Sec with proper air flow) 95A
Dimension (mm) 64x30x14
Wire Size 12awg
Weight (g) 73g
Download User Manual

Air 120
P/N 6VSARA2001
Support Li-Po Cell 2S~6S
BEC Switching
Continuous Current 120A
Burst Current (15 Sec with proper air flow) 150A
Dimension (mm) 58x43x17
Wire Size 10awg
Weight (g) 128g
Download User Manual
